Steute IS M30
金屬外殼
M30 x 1.5螺紋
嵌入式安裝
壽命長，無機械磨損
對污垢不敏感
帶LED
帶預接線電纜或插入式連接器
技術數據
應用標準EN 60947-5-2
外殼黃銅，有刻痕
前蓋聚碳酸酯
防護等級IP 67，符合IEC/EN 60529
連接電纜PVC（4.6 mm）3 x 0.35 mm²或插入式連接器M12 x 1
開關元件1 NO觸點，PNP，3線
額定開關距離sn 10 mm
校正系數鋼（Fe360）=1；不銹鋼約0.7；黃銅約0.5；鋁約0.4；銅約0.4
額定工作電壓范圍UB 10…30 VDC
殘余波紋≤10%
開關電流。零點二一
Ie時的電壓降。1.8伏
24 VDC時電流吸收<15 mA
滯后約。10%
開關頻率300 Hz
重復性≤3%
保護電路感應干擾保護、極性反轉保護、短路保護和過載保護
LED顯示屏在啟動時亮起黃色
環境溫度-25°C…+85°C
帶預接線電纜
類型 物料編號
Steute IS M30b 10AAACA PNP NO 2m1202194
帶插入式連接器
類型 物料編號
Steute IS M30b 10AAAC PNP 無 ST21202196
